全频通道 Main Channels @ 4 Ω |
100 W RMS x 4 |
|
全频通道 Main Channels @ 2 Ω |
130 W RMS x 4 |
|
全频通道 Main Channels - Bridged @ 8 Ω |
100 W RMS x 2 |
|
全频通道 Main Channels - Bridged @ 4 Ω |
150 W RMS x 2 |
|
低频通道 Subwoofer Channel @ 4 Ω |
500 W RMS x 1 |
|
低频通道 Subwoofer Channel @ 2 Ω |
700 W RMS x 1 |
通用指标General Specifications
|
频率响应 Frequency Response 全频 Main Channels (0至-3dB) |
20 Hz - 20k Hz |
|
频率响应 Frequency Response 低频 Subwoofer Channel (0至-3dB) |
20 Hz – 300 Hz |
|
信噪比 S/N Ratio 全频 Main Channels |
≥100dB A计权，额定功率 1%THD |
|
信噪比 S/N Ratio 低频 Subwoofer Channel |
≥85dB A计权，额定功率 1%THD |
|
阻尼系数 Damping Factor @ 4 Ω 全频Main Channels |
> 200 |
|
阻尼系数 Damping Factor @ 4 Ω 低频Subwoofer Channel |
> 150 |
|
THD+N 1k Hz 10% 额定功率 1k Hz 10% Rated Power 全频 Main Channels |
< 0.1% |
|
THD+N @ Rated Power 低频 Subwoofer Channel |
< 0.05% |
|
输出短路保护 Output Short Circuit Protection |
√ |
|
高温保护 High Temperature Protection |
85 ℃ |
|
电源极性保护 Power Supply Polarity Protection |
√ |
|
电源过压保护 Power Supply Overvoltage Protection |
33 V |
|
工作电压 DC Operating Voltage |
20 V-29 V |
|
噪声电压 Noise Voltage |
2.1 mV |
|
空载电流 No-load Current |
900 mA |
|
输入阻抗 Input Impedance |
10k Ω |
|
工作温度范围 Operating Temperature Range |
-20 - +80 ℃ |
信号处理Signal Processing
|
总音量增益范围 Total Volume Gain Range |
-60 ~ +6 dB |
|
每声道音量增益范围 Volume Gain Range per channel |
-60 ~ +0 dB |
|
EQ调节频段 EQ Adjustment Frequency Band |
31 Band |
|
EQ每频率段增益范围 EQ Gain Range per frequency band |
-12 ~ +12 dB |
|
巴特沃斯低通 Butter Low Pass |
6~48 dB/Oct |
|
贝塞尔低通 Bessel Low Pass |
6~48 dB/Oct |
|
宁克低通 Link Low Pass |
6~48 dB/Oct |
|
巴特沃斯高通 Butter High Pass |
6~48 dB/Oct |
|
贝塞尔高通 Bessel High Pass |
6~48 dB/Oct |
|
宁克高通 Link High Pass |
6~48 dB/Oct |
|
延时 Delay |
0 ~ 20 ms |
尺寸Specifications
|
高 Height (H) |
61 mm |
|
宽 Width (W) |
260 mm |
|
深 Depth (D) |
172 mm |
|
净重 Net Weight |
3.1 kg |
